Seamless 'No Spot' COB LED Strip Lights
'COB' dotless LED Strip products which offer NO VISIBLE SPOTTING. It's not often that there is a step-change in product design but perhaps this is one in the field of LED Strip. Manufacturing technology has now moved on so that the incredibly small LED's which are usually mounted in a larger package so that they can be handled, can now be mounted directly onto the PCB meaning many, many more can be packed into a smaller space which in turn means no visible spotting.
Item No.
Color
LEDs/unit
LEDs/m
PCB Width (mm)
PCB Thickness (OZ)
Cutting Length (mm)
lm/m CRI>80/90
Viewing Angle
Voltage (V)
Power (W/M)
AR-FS-COB-320
W
16
320
8
2
50
1000/900
180
24
8
AR-FS-COB-420
W
21
420
10
2
50
1250/1000
180
24
12
AR-FS-COB-480
W
24
480
10
2
50
1800/1600
180
24
15
1.Own R&D OEM is welcome
2.24 hours on line one to one service
3.All inquiry will be replied within 24 hours
4.8 year golden & verified supplier in Alibaba
5.Free replacement
6.Strict quality control
Features:
COB high density
Even lighting output
Free splicing Flip chip technology based on flexible substrate led chips soldered directly on FPCB, makes the light ultra high reliability, flat surface.
High flexible arbitrary bending long durability Cuttable and Linkable
Advantages:
1. Overall thickness 0.6mm,flat appearance,regular,consistent ,bring unlimited space to the design 2. The emitted light is continuous uninterrupted and uniform linear light, and there is no dark area at any close distance. 3. Uniform brightness at each point,no dazzle, no glare 4. Flip-chip process, no dead light risk, 1000 high temperature and low temperature thermal shock test (-40 °C / +100 °C) 5. Single core current is small, the lamp has low heat and long life 6. Multi-dimentional parallel protection, even if the single core loss is abnormally damaged, no dark light 7. The lamp strip substrate is resistant to vulcanization, has high halogenation ability, is lit for a long time, and has consistent color consistency. 8. Arbitrary node,bend at any angle.Extreme winding aging for more than 10,000 hours.
